Tripp-Lite B112-002-R Manual VGA/SVGA 2 Position Push Button Switch

Tripp-Lite B112-002-R Manual VGA/SVGA 2 Position Push Button Switch

MSRP: $21.14
$13.99
(You save $7.15 )
SKU:
B112-002-R
Shipping:
Calculated at Checkout
In Stock
Available
Before Ordering

Availability and lead times may vary. Request a quote if you need to confirm availability before placing your order.

Family Owned Since 1932
Nationwide Shipping Serving all 50 states
Technical Support Product selection assistance
Project Assistance Quotes and sourcing support

Description

Overview

Tripp Lite's 2-Port Manual VGA/SVGA Switch is the optimal solution for connecting two computers to one monitor or two monitors to one computer. The 2-Port Manual VGA/SVGA Switch features a fully-shielded rugged metal case with front-panel push-button switching. Interior printed circuit board design allows for crystal clear resolutions up to 1600x1280. It does not require any AC power to operate.

Features

  • Connects two computers to one monitor or two monitors to one computer
  • Fully-shielded rugged metal case with front-panel push button switch
  • Does not require external power, software, or complicated set-up procedures

System Requirements

  • Computer with an HD15 port
  • VGA or SVGA monitor with HD15M cable

Package Includes

  • B112-002-R Manual VGA/SVGA 2 Position Switch
RoHS compliant

Specifications

OVERVIEW
UPC Code 037332014269
Technology VGA/SVGA
VIDEO
Max Supported Video Resolution 1920 x 1080 @60Hz
INPUT
Bus Powered   Yes
Product Length (in.) 4.41
Product Length (ft.) 0.37
POWER
Power Consumption (Watts) 0.5
PHYSICAL
Material of Construction Aluminum
Color Silver
Shipping Dimensions (hwd / in.) 4.53 x 1.06 x 3.27
Shipping Weight (lbs.) 3.53
Unit Dimensions (hwd / in.) 0.94 x 4.4 x 2.7
Unit Packaging Type Box
Unit Weight (lbs.) 0.33
ENVIRONMENTAL
Operating Temperature Range 14 to 131 °F (-10 to 55 °C)
Storage Temperature Range 5 to 131 °F (-15 to 55 °C)
Relative Humidity 5% to 90% RH, Non-Condensing
BTUs   1.7 BTU/Hr
COMMUNICATIONS
EDID Compatible   Yes
CONNECTIONS
Number of Ports 2
Side A - Connector 1 (2) HD15 (FEMALE)
Side B - Connector 1 HD15 (FEMALE)
Connector Plating Nickel
FEATURES & SPECIFICATIONS
Port Selection Pushbutton
Driver Required No
STANDARDS & COMPLIANCE
Certifications CE, FCC, RoHS, REACH
WARRANTY
Product Warranty Period (Worldwide) 1-year limited warranty
