Product Overview
Features
Reliable Power for Mobile, Emergency and Remote Sites
Pure Sine-Wave Power for Normal and Peak Power Demands
Automatic Transfer Switching
3-Stage 4/40A Selectable Battery Charger
External Ports
Easy Operation
Rugged Steel Housing
- Generates 230V pure sine-wave power from 12V battery bank
- Ideal for powering variable-speed tools, computers, LEDs, fans, audio/video components and other sensitive electronics
- Designed for easy installation in RVs, fleet vehicles and emergency vehicles
- Functions as vehicle inverter, standalone AC power source or extended-run UPS
- Unlimited runtime with variety of user-supplied batteries
Pure Sine-Wave Power for Normal and Peak Power Demands
- 1000W of continuous power
- 2000W of peak power to accommodate surge power demands during equipment startup and cycling
- Automatic overload detector, built-in cooling fan and resettable AC circuit breakers protect unit from damage
- High-current DC input terminals for simple hardwired installation
Automatic Transfer Switching
- Transfer relay switches to inverter power during blackout in 16.6 ms
- DIP switches configure high and low voltage auto-transfer
3-Stage 4/40A Selectable Battery Charger
- Serves as battery charger when external 230V AC power is supplied and powering connected equipment
- Protects battery from overcharging and overdischarging
- Low-battery protection prevents excessive battery depletion
- DIP switches configure wet/gel charging profiles
External Ports
- Battery temperature port allows connection of optional remote battery temperature sensor, such as Tripp Lite's APSSWTEMP
- RJ45 communication port allows connection of optional remote control module, such as Tripp Lite's APSRMSW with 32-ft. (9.75 m) cord
Easy Operation
- LEDs indicate battery voltage, charger and inverter status
- On/off button provides one-touch control
Rugged Steel Housing
- Resists moisture, vibration, impact and high-humidity environments
- Built-in mounting feet for installation on any rigid horizontal surface
Package Includes
- APSX1012SW 1000W APS XSeries 12V DC 230V AC Inverter/Charger
- Owner’s manual
Specifications
OVERVIEW
| UPC Code | 037332161338 |
INPUT
| Nominal Input Voltage(s) Supported | 220V AC; 230V AC; 240V AC |
| Nominal Input Voltage Description | 170-264V +/- 3% |
| Maximum Input Amps / Watts | DC INPUT: Full continuous load - 240A at 12VDC. AC INPUT: 17 amps at 230VAC with full inverter and charger load (8.7A max charger-only / combined input load to support charger and AC output is automatically controllable to 66%-33%-0% based on AC output loading using the charger limiting set points - see manual for setting instructions) |
| Recommended Electrical Service | DC INPUT: Requires 12VDC input source capable of delivering 240A for the required duration (when used at full continuous capacity - DC requirements increase during OverPower and DoubleBoost operation). For automotive applications, professional hardwire installation with 200A minimum battery system fusing is recommended. |
| Input Connection Type | DC INPUT: Set of 2 DC bolt-down terminals. AC INPUT: Hardwire via built in junction box with cover plate |
| Voltage Compatibility (VAC) | 220-240 |
| Voltage Compatibility (VDC) | 12 |
OUTPUT
| Frequency Compatibility | 50 / 60 Hz |
| Pure Sine Wave Output | Yes |
| Output (Watts) | 1000 |
| Nominal Output Voltage(s) Supported | 230V |
| Output Receptacles | Hardwire |
| Continuous Output Capacity (Watts) | 1000 |
| Peak Output Capacity (Watts) | 2000 |
| Output Voltage Regulation | Nominal 230v +/- 5% |
| Output Frequency Regulation | 50/60 Hz (+/- 0.5 Hz) |
| Overload Protection | Includes 7A input breaker dedicated to the charging system and 7A output breaker for AC output loads |
BATTERY
| Expandable Battery Runtime | Runtime is expandable with any number of user supplied wet or gel type batteries |
| Expandable Runtime | Yes |
| DC System Voltage (VDC) | 12 |
| Battery Pack Accessory (Optional) | 98-121 sealed lead acid battery(optional) |
| Battery Charge | Includes selectable 4~40 amp DC charging system. |
USER INTERFACE, ALERTS & CONTROLS
| Front Panel LEDs | Set of front panel LED's display inverter status, charger status, as well as battery voltage status |
| Switches | The inverter provides a RJ-45 port for optional APSRMSW remote control. RJ45 port operates with standard RS485 interface (APSRMSW sold separately) |
| Audible Alarm | Audible status indicators 10.5V (low battery)/21V start alarm |
PHYSICAL
| Material of Construction | Powder-Coated Steel |
| Cooling Method | Fan |
| Form Factors Supported | Mounting slots enable permanent placement of inverter on any horizontal surface (see manual for additional mounting information) |
| Receptacle Color | Grey |
| Shipping Dimensions (hwd / in.) | 13.00 x 12.60 x 21.47 |
| Shipping Weight (lbs.) | 36.37 |
| Unit Dimensions (hwd / in.) | 7.25 x 8.75 x 18 |
| Unit Weight (lbs.) | 31.5 |
ENVIRONMENTAL
| Relative Humidity | 0-95% non-condensing |
LINE / BATTERY TRANSFER
| Transfer Time (Line Power to Battery Mode) | 16 ms. maximum |
| Low Voltage Transfer to Battery Power | 170 VAC (+/- 3%) DEFAULT OR 190V +/-3% (user-selectable) |
| High Voltage Transfer to Battery Power | 264 VAC +/- 3% |
FEATURES & SPECIFICATIONS
| Load Sensing | 100W |
STANDARDS & COMPLIANCE
| Approvals | Tested to EN62040-1 (CE), EN62040-2 (EMC), RoHS |
WARRANTY
| Product Warranty Period (U.S. & Canada) | 2-year limited warranty |
