Category 6 MT-Series Keystone Jack, T568A/B Wiring, White
The Signamax Category 6 MT-Series Unscreened Keystone Jacks have been designed to meet the need for today’s high-bandwidth applications. These connectors are slim in profile for the highest density applications and have the ability to mount either color-coded icons for service identification or dust covers to protect unused jacks from dust and other contaminants.
The contact design provides enhanced plug-to-jack connection integrity, protects against damage caused by insertion of 4- or 6-position plugs. Special design features allow these jacks to be terminated with a standard 110 single-position tool or with the Signamax four-pair tool, and are rated for a minimum of 750 plug insertions providing for the highest level of system reliability.
FEATURES
- Exceeds TIA-568-C.3 component performance specifications
- Slim profile for the highest density applications
- Improved wire retention and ease of termination with rear 110 type contacts
- Meets IEC 60603-7, Supports IEEE 802.3af, 802.3at, and IEEE 802.3bt type 3 and 4 PoE applications
- Compatible with Signamax screened snap-in patch panels and work area faceplates
- Circuit identification icons, dust covers, and 110 protection caps included in kit
- Available in convenient pack of 25 and master pack of 500 jacks
