Description
Key Features:
- Rugged IP40 enclosure with integrated DIN-Rail mounting bracket
- Wide operating temperature: -40 to 167 ¡F (-40 to 75 ¡C)
- Surge protection (4kV LAN) for extreme outdoor environments
- Redundant terminal block DC inputs
- Overload and reverse polarity protection
- Zero touch Plug and Play connectivity
- Non-Blocking, wire speed media conversion
- Fixed fiber Multimode
- 5 year hardware warranty & support at no additional cost
Specifications:
PORTS
RJ-45 Ports: 2 – 10/100
Uplink Ports: 1 – SC/SM
PERFORMANCE
Wirespeed forwarding
LAYER 2
IEEE 802.3 10BaseT
IEEE 802.3u 100BaseTX
IEEE 802.3u 100BaseFX
IEEE 802.3 Auto-Negotiate
IEEE 802.3x Flow Control
ELECTRICAL CHARACTERISTICS
Max Power Consumption: 4W
MTBF: 539K hrs
DC Input Range: 12 ~ 48V DC, Dual Redundant
4kV LAN surge protection
Reverse polarity and overload current protection
PHYSICAL CHARACTERISTICS
Dimensions: 1.2” W x 4.7” H x 3.9” D (3 x 11.9 x 10 cm)
Weight: 0.78 lb (0.35 kg)
Housing: IP40 protection, aluminum alloy case
Mounting: DIN-Rail mounting (included)
ENVIRONMENTAL REQUIREMENTS
Operating Temperature: -40°F to 167°F (-40°C to 75°C)
Storage Temperature: -40 to 185°F (-40 to 85°C)
Operating/Storage Humidity: 5 to 95% (non-condensing)
CERTIFICATIONS
Emissions: CE Mark: EN 55022, Class A; FCC Part 15 Class A
Safety: CE/LVD EN60950
WARRANTY
Five years
