Product Overview
DESCRIPTION
10/100/1000BaseT/TX to 1000BaseLX Media Converter, SC/SM, 20 km Span
The Signamax 10/100/1000 to 1000 SX/LX Switching Media Converters provide an intelligent solution for long distance connections between legacy 10BaseT and 100BaseTX networks and 1000Base Gigabit Ethernet networks. The built-in switch enables the fiber cable connection to operate at 1000 Mbps connected to either a 10BaseT, 100BaseTX, or a 1000BaseT network, while remaining completely 1000BaseSX or 1000BaseLX standard-compliant for the fiber optic connection. The fiber connection can also operate in full duplex mode whether the RJ-45 port is connected to a full duplex switch or a half duplex legacy hub.
Improvements in the this series of media converters include: extremely low latency, the ability to force the RJ-45 port to 100Base or 10Base full or half-duplex modes, provide auto-negotiation on the 1000Base fiber port or forced full-duplex mode where required, and the enabling or disabling of the Link Fault Signaling feature.
FEATURES
- Extremely low latency supports larger multi-hop networks
- Extremely high reliability; MTBF of over 112 years
- Gigabit transmission supports 9K bytes jumbo frames
- IEEE 802.3x flow control for full duplex and back pressure for half duplex supported
- DIP switch configuration for link fault signalling, fiber auto/force mode, and SFP speed
- Full wire-speed forwarding rate
- Supports wall mounting, DIN-rail mounting or use with media converter rack mount chassis
