Description
FEATURES
- Absorbent Glass Mat (AGM) technology for superior performance
- Valve regulated, maintenance free spill proof construction
- Power/volume ratio yielding excellent energy density
- Rugged vibration and impact resistant ABS case and cover
- Gas recombination technology
- 5 year design life
APPROVALS
- Approved for transport by air. D.O.T., I.A.T.A., F.A.A. and C.A.B. certified
- U.L. recognized
- ISO9001:2015 – Quality management systems
PERFORMANCE SPECIFICATIONS
- Nominal Voltage 12 volts (6 cells)
- Nominal Capacity
- 20-hr. (450mA to 10.50 volts) 9.00 AH
- 10-hr. (810mA to 10.50 volts) 8.10 AH
- 5-hr. (1.44A to 10.20 volts) 7.20 A
- 1-hr. (5.40A to 9.00 volts) 5.40 AH
- Approximate Weight: 6.00 lbs. (2.72 kg)
- Internal Resistance (approx.): 13.0 milliohms
- Max Short-Duration Discharge Current (10 Sec.): 90.0 amperes
- Shelf Life (% of nominal capacity at 68°F (20°C)
- 1 Month: 97%
- 3 Month: 91%
- 6 Month: 83%
- Operating Temperature Range:
- Charge: 5°F (-15°C) to 122°F (50°C)
- Discharge: -4°F (-20°C) to 140°F (60°C)
- Case: ABS Plastic
- Power Sonic Chargers:
- PSC-121000-PC
- PSC-122000A-C
- PSC-122000-PC
