Description
Harness Cable Tie Mount
THMSC35-C30 Cable Tie Mount
Secure wire harness assemblies in high temperature areas with our harness cable tie mount so your cables stay retained over the long term.
Specifications
- Note: High Temperature
- Material Description: Nylon 6.6 (Heat-Resistant)
- Product Type: Cable Tie Mount
- Application: Harness Cable Tie Mount is Applied With a Fir Tree Push Barb, for Indoor and High-Temperature Environments
- Color: Black
- Flammability Rating: UL 94 V-2
- Environment: Indoor
- Material: Nylon 6.6
- Material Properties: Heat-Stabilized
- Maximum Compatible Panel Thickness (In.): 0.25
- Maximum Compatible Panel Thickness (mm): 6.4
- Maximum Operating Temperature (°C): 115
- Maximum Operating Temperature (°F): 239
- Minimum Operating Temperature (°C): -60
- Minimum Operating Temperature (°F): -76
- Minimum Loop Tensile Strength (N): 222
- Minimum Loop Tensile Strength (lb): 50
- Mount Method: Fir Tree Mount
- Overall Length (In.): 1.54
- Overall Length (mm): 39.1
- Overall Width (In.): 0.37
- Overall Width (mm): 9.4
- Overall Height (In.): 0.68
- Overall Height (mm): 17.3
- Resistance Properties: Heat-Resistant
- Standards Met: cULus 62275 Type 1,11 (Recognized, E136577), CE Compliant, RoHS Compliant
- For Use With: Miniature, Intermediate, Standard Cross-Section Ties
Manufacturer Standard Package Quantity: 100
