Description
Pan-Net® TX6™ Category 6 Unshielded (U/UTP) Copper Cable
Copper Cable, Cat 6, 23 AWG, U/UTP, CMR, Blue
Ensure top-tier network performance with our Cat 6 U/UTP copper cable, available in multiple colors for clear labeling.
Specifications
- Environment: Indoor
- Performance Level: Category 6
- Cable Construction: U/UTP
- Shield Type: Unshielded
- Jacket Material: PVC
- Flammability Rating: Riser (CMR)
- Resistance Properties: Flame-Retardant
- Nominal Cable Outside Diameter (In.): 0.21
- Nominal Cable Outside Diameter (mm): 5.3
- Maximum Operating Temperature (°C): 75
- Maximum Operating Temperature (°F): 167
- Minimum Operating Temperature (°C): -20
- Minimum Operating Temperature (°F): -4
- Maximum Installation Temperature (°C): 50
- Maximum Installation Temperature (°F): 122
- Minimum Installation Temperature (°C): 0
- Minimum Installation Temperature (°F): 32
- Sub Brand: Pan-Net®
- Maximum Installation Tension (N): 110
- Maximum Installation Tension (lb): 25
- Bend Radius (In.): 0.83
- Bend Radius (mm): 21
- Number of Pairs: 4
- Conductor Material: Copper
- Conductor Type: Solid
- Overall Length (ft.): 1,000
- Overall Length (m): 305
- Conductor Gauge: 23 AWG
- Conductor Gauge (mm): 0.57
- Insulation Material: Polyolefin
- Insulation Diameter (In.): 0.039
- Insulation Diameter (mm): 1
- Maximum Voltage (V): 80
- Standards Met: Exceeds ANSI/TIA-568.2-D Category 6 and ISO 11801 Class E with Channel Headroom Guarantee, meets IEEE 802.3af, IEEE 802.3at and IEEE 802.3bt for PoE applications, UL 1666 and CSA FT-4, RoHS Compliant.
- Color: Blue
- Packaging Type: Carton
- Product Type: Bulk Copper Cable
- Manufacturer Status: Discontinued - Limited Stock
Manufacturer Standard Package Quantity: 1000
