Description
Contour Multiple Tie Plate
MTPC2H-E10-C39 Cable Tie Mount
Designed for the aerospace industry, our contour multiple tie plate minimizes abrasion while its low-profile design keeps your bundles close to the mounting surface.
Specifications
- Material Description: Nylon 6.6 (UV-Resistant, Weather-Resistant)
- Product Type: Cable Tie Mount
- Application: Low Profile Multiple Tie Plates Used to Secure Closely Spaced Wire Bundles
- Color: Natural
- Environment: Indoor
- Material: Nylon 6.6
- Material Properties: Heat-Stabilized
- Maximum Operating Temperature (°C): 115
- Maximum Operating Temperature (°F): 239
- Minimum Operating Temperature (°C): -60
- Minimum Operating Temperature (°F): -76
- Mount Method: Screw-On
- Compatible Screw Size: #10
- Overall Length (In.): 3.59
- Overall Length (mm): 91.2
- Overall Width (In.): 0.62
- Overall Width (mm): 15.8
- Overall Height (In.): 0.2
- Overall Height (mm): 5.1
- Resistance Properties: UV-Resistant, Weather-Resistant
- Standards Met: RoHS Compliant
- For Use With: Miniature, Intermediate, Standard, Light-Heavy Cross-Section Ties
Manufacturer Standard Package Quantity: 100
