Panduit LCMD70-12-X

$2,158.99
SKU:
LCMD70-12-X
Shipping:
Calculated at Checkout
Before Ordering

Availability and lead times may vary. Request a quote if you need to confirm availability before placing your order.

Family Owned Since 1932
Nationwide Shipping Serving all 50 states
Technical Support Product selection assistance
Project Assistance Quotes and sourcing support

Description

Pan-Lug™ Copper 2 Hole Straight Tongue Compression Lug in Metric Sizing

Pan-Lug™ LCMD70-12-X Copper Compression Connectors - Metric Lugs

Two holes for added stability and a straight tongue for easy installation in electrical applications, our compression lug ensure reliable and secure electrical connections. Available in metric sizes.

Specifications

  • Product Type: Metric Compression Lug
  • Base Material: Copper
  • Number of Stud Holes: 2
  • Barrel Type: Standard
  • Barrel Entry: Beveled
  • Tongue Type: Standard
  • Tongue Angle: Straight
  • Inspection Window: Yes
  • Finish/Coating: Tin-Plated
  • Stud Hole Size (mm): 12
  • Stud Hole Spacing (mm): 44.5
  • Metric Class 2r Copper Conductor Size (mm²): 70
  • Metric Class 5f-6f Copper Conductor Size (mm²): 50
  • Barrel Length (mm): 23.3
  • Tongue Width (mm): 21.3
  • Tongue Thickness (mm): 2.8
  • Overall Length (mm): 98
  • Standards Met: Meets EN 61238-1:2003/IEC 61238-1:2003 Class B WITH Class 2r Wire, UKCA compliant, CE compliant,UL Listed to 486A-486B File #E52164, CSA certified C22.2 No. 65-13
  • CSA Temperature Rating (°C): 90
  • UL Temperature Rating (°C): 90
  • Maximum Voltage (kV): 35
  • Color Code: Black
  • Panduit Die Index Number: P45
  • Wire Strip Length (mm): 24.8
  • Note: Consult cable manufacturer for voltage stress relief instructions with applications greater than 2000 V
  • Sub Brand: Pan-Lug™

Manufacturer Standard Package Quantity: 10
