Description
Pan-Lug™ Copper 2 Hole 90° Tongue Compression Lug
Pan-Lug™ LCD2-14BF-Q Copper Compression Connectors - Lugs
Double the stability with two mounting holes for secure connections of large electrical wires in demanding installations with our 90° angle tongue compression lug.
Specifications
- Product Type: Compression Lug
- Base Material: Copper
- Number of Stud Holes: 2
- Barrel Type: Standard
- Barrel Entry: Beveled
- Tongue Type: Standard
- Tongue Angle: 90°
- Inspection Window: Yes
- Finish/Coating: Tin-Plated
- Stud Hole Size (In.): 1/4
- Stud Hole Size (mm): 6.4
- Stud Hole Spacing (In.): 3/4
- Stud Hole Spacing (mm): 19.1
- Copper Conductor Size: 2 AWG
- Barrel Length (In.): 0.88
- Barrel Length (mm): 22.4
- Tongue Width (In.): 0.6
- Tongue Width (mm): 15.3
- Tongue Thickness (In.): 0.1
- Tongue Thickness (mm): 2.6
- Overall Length (In.): 1.99
- Overall Length (mm): 50.6
- Standards Met: CSA certified C22.2 No. 65-13, UL Listed to 486A-486B File #E52164, NEBS Level 3
- CSA Temperature Rating (°C): 90
- UL Temperature Rating (°C): 90
- Maximum Voltage (kV): 35
- Color Code: Brown
- Panduit Die Index Number: P33
- Burndy Die Index Number: 10
- T & B Die Index Number: 33
- Wire Strip Length (In.): 15/16
- Wire Strip Length (mm): 23.8
- Note: Consult cable manufacturer for voltage stress relief instructions with applications greater than 2000 V
- Sub Brand: Pan-Lug™
- Part Features: Tin plated to inhibit corrosion,color coded barrel,inspection window, NEBS level 3.
Manufacturer Standard Package Quantity: 25
