Description
Pan-Lug™ Copper 2 Hole Straight Tongue Compression Lug
Pan-Lug™ LCC1-12-E Copper Compression Connectors - Lugs
Two holes for added stability and a straight tongue for easy installation in electrical applications, our compression lug ensure reliable and secure electrical connections.
Specifications
- Product Type: Compression Lug
- Base Material: Copper
- Number of Stud Holes: 2
- Barrel Type: Long
- Barrel Entry: Beveled
- Tongue Type: Standard
- Tongue Angle: Straight
- Inspection Window: No
- Finish/Coating: Tin-Plated
- Stud Hole Size (In.): 1/2
- Stud Hole Size (mm): 12.7
- Stud Hole Spacing (In.): 1-3/4
- Stud Hole Spacing (mm): 44.5
- Copper Conductor Size: 1 AWG
- Barrel Length (In.): 1.36
- Barrel Length (mm): 34.5
- Tongue Width (In.): 0.75
- Tongue Width (mm): 19.1
- Tongue Thickness (In.): 0.09
- Tongue Thickness (mm): 2.3
- Overall Length (In.): 4.74
- Overall Length (mm): 120.4
- Standards Met: CSA certified C22.2 No. 65-13, UL Listed to 486A-486B File #E52164, ABS approved, NEBS Level 3
- CSA Temperature Rating (°C): 90
- UL Temperature Rating (°C): 90
- Maximum Voltage (kV): 35
- Color Code: Green
- Panduit Die Index Number: P37
- Burndy Die Index Number: 11
- T & B Die Index Number: 37
- Wire Strip Length (In.): 1-7/16
- Wire Strip Length (mm): 36.5
- Note: Consult cable manufacturer for voltage stress relief instructions with applications greater than 2000 V
- Sub Brand: Pan-Lug™
- Part Features: Tin plated to inhibit corrosion,color coded barrel, NEBS level 3.
Manufacturer Standard Package Quantity: 20
