Description
Panduct® Type G Wide Slot Wiring Duct
Panduct® G2X4IB6 Base Wiring Duct
Our Type G wide slot wiring duct securely accommodates various wire bundle sizes with its rigid design, enabling flexible cable organization in control panels and electrical enclosures.
Specifications
- Product Type: Base Wiring Duct
- Application: Wide slot/finger design provides greater sidewall rigidity and can be used in a wide range of applications
- Color: Intrinsic Blue
- Cover Part Number: C2IB6
- Flammability Rating: UL 94 V-0
- Includes: (1) Base
- Note: Cover sold separately
- Standards Met: RoHS Compliant, UL Recognized, CE Compliant, BABA Compliant
- Material: PVC
- Material Properties: Lead-Free
- Mount Method: Mounting Holes
- Measurement System: Imperial
- Wiring Duct Style: Wide Slot Wiring Duct
- Wiring Duct Type: G
- Nominal Width (In.): 2
- Nominal Height (In.): 4
- Overall Length (ft.): 6
- Overall Length (m): 1.83
- Overall Width (In.): 2.25
- Overall Width (mm): 57.2
- Overall Height (In.): 4.1
- Overall Height (mm): 104.1
- Slot Width (In.): 0.31
- Slot Width (mm): 7.9
- Sub Brand: Panduct®
- Part Features: Wide finger and slot design provides greater rigidity and allows use with a wide range of wire and bundle sizes. Upper and lower scorelines allows easy finger and sidewall section removals.
Manufacturer Standard Package Quantity: 6
