Description
Single Wire Ferrule with End Sleeve
Pan-Term® FSD75-10-D Covered Single Wire Ferrules
Simplifies reliable connections with our single wire ferrule with end sleeve for stranded wires in terminal blocks, meeting industry standards for various applications.
Specifications
- Note: UL with 20 AWG wire only
- Ferrule Type: Single Wire Standard
- Cover Material: Polypropylene
- Copper Conductor Size: 22-20 AWG
- Maximum Metric Conductor Size (mm²): 0.5
- Minimum Metric Conductor Size (mm²): 0.5
- UL Temperature Rating (°C): 105
- CSA Temperature Rating (°C): 105
- Flammability Rating: UL 94 HB
- Wire Strip Length (In.): 17/32
- Wire Strip Length (mm): 13.5
- Pin Length (In.): 0.39
- Pin Length (mm): 10
- Inside Diameter (In.): 0.04
- Inside Diameter (mm): 0.09
- Maximum Operating Temperature (°C): 105
- Maximum Operating Temperature (°F): 221
- Minimum Operating Temperature (°C): -54
- Minimum Operating Temperature (°F): -60
- Maximum Wire Insulation Diameter (In.): 0.09
- Maximum Wire Insulation Diameter (mm): 2.5
- Overall Length (In.): 0.61
- Overall Length (mm): 15.5
- Product Type: Covered Single Wire Ferrule
- Standards Met: DIN 46228, CSA C22.2 No. 291-14, UL 486F, cULus 486F (with 20 AWG wire only)
- Finish/Coating: Tin-Plated
- For Use With: CT-1002, CT-1003, CT-1090, CT-1123, CT-1160, CT-1170, CP-991, CTFP-25, CTFP-40, CT-2300/ST (CD-090), CT-2500/L (CT-2523CH)
- Packaging Type: Bag
- Base Material: Copper
- Color Code: White
- Sub Brand: Pan-Term®
- Part Features: Polypropylene covered housing conforms to DIN color requirements. Meets DIN, UL and CSA standards for single wire containment. Funnel entry for faster insertion and lower installed cost. Designed with a seamless barrel to contain loose wire strands for superior terminations. Eases insertion of wire into terminal block. Suitable for limited space panel applications. Multiple pin lengths available for a variety of terminal blocks
Manufacturer Standard Package Quantity: 500
