Panduit ESFLHT5C02FGR-X

$2,492.99
SKU:
ESFLHT5C02FGR-X
Shipping:
Calculated at Checkout
Before Ordering

Availability and lead times may vary. Request a quote if you need to confirm availability before placing your order.

Family Owned Since 1932
Nationwide Shipping Serving all 50 states
Technical Support Product selection assistance
Project Assistance Quotes and sourcing support

Description

PROFINET Type B/C Category 5e Shielded (SF/UTP) Copper Cable

IndustrialNetTM Copper Cable, Cat 5e, 22 AWG, SF/UTP, Green

Robust and flexible, our Cat 5e SF/UTP copper cable with TPE jacket resists oil, sunlight, and abrasion. Perfect for industrial automation and outdoor use.

Specifications

  • Environment: Outdoor
  • Performance Level: Category 5e
  • Cable Construction: SF/UTP
  • Shield Type: Shielded
  • Jacket Material: TPE
  • Flammability Rating: CMX/CMR
  • Resistance Properties: Flame-Retardant
  • Nominal Cable Outside Diameter (In.): 0.31
  • Nominal Cable Outside Diameter (mm): 7.9
  • Maximum Operating Temperature (°C): 75
  • Maximum Operating Temperature (°F): 167
  • Minimum Operating Temperature (°C): -40
  • Minimum Operating Temperature (°F): -40
  • Maximum Installation Temperature (°C): 75
  • Maximum Installation Temperature (°F): 167
  • Minimum Installation Temperature (°C): -40
  • Minimum Installation Temperature (°F): -40
  • Sub Brand: IndustrialNet™
  • Maximum Installation Tension (N): 50
  • Maximum Installation Tension (lb): 11.2
  • Number of Pairs: 2
  • Conductor Material: Copper
  • Conductor Type: Solid
  • Overall Length (ft.): 1,000
  • Overall Length (m): 305
  • Conductor Gauge: 22 AWG
  • Conductor Gauge (mm): 0.64
  • Insulation Material: Polyethylene
  • Insulation Diameter (In.): 0.05
  • Insulation Diameter (mm): 1.3
  • Maximum Voltage (V): 600
  • Standards Met: Standard compliances: UL AWM Style 2463 (80C 600V), UL Type PLTC, UL Type ITC, Sun Res, Oil Res, Weld spatter Res; CE Compliant: EuroClass Eca; RoHS Compliant
  • Color: Green
  • Packaging Type: Reel
  • Product Type: Bulk Copper Cable
  • Manufacturer Status: Discontinued

Manufacturer Standard Package Quantity: 1
