Panduit EQSP18D-Q

$22.99
SKU:
EQSP18D-Q
Shipping:
Calculated at Checkout
Before Ordering

Availability and lead times may vary. Request a quote if you need to confirm availability before placing your order.

Family Owned Since 1932
Nationwide Shipping Serving all 50 states
Technical Support Product selection assistance
Project Assistance Quotes and sourcing support

Description

StrongHold™ Polypropylene-Insulated Quick Splice

StrongHold™ EQSP18D-Q Quick Splice

Make fast electrical connections with our polypropylene quick splice so your repairs get secure, reliable joints that last across many applications.

Specifications

  • Product Type: Quick Splice
  • Base Material: Brass
  • Finish/Coating: Tin-Plated
  • Copper Conductor Size: 22-18 AWG
  • Maximum Metric Conductor Size (mm²): 0.8
  • Minimum Metric Conductor Size (mm²): 0.5
  • Barrel Length (In.): 0.76
  • Barrel Length (mm): 19.4
  • Overall Length (In.): 0.79
  • Overall Length (mm): 20.1
  • Overall Width (In.): 0.46
  • Overall Width (mm): 11.7
  • Overall Height (In.): 0.48
  • Overall Height (mm): 12.2
  • Standards Met: cULus
  • CSA Temperature Rating (°C): 105
  • Maximum Voltage (V): 600
  • Maximum Voltage (kV): 0.6
  • Color Code: Red
  • Sub Brand: StrongHold™

Manufacturer Standard Package Quantity: 25
