Description
Panduct® Type D Round Hole Wiring Duct
Panduct® D2X2LG6 Base Wiring Duct
Our Type D round hole wiring duct simplifies your wire management with flexible routing options, protecting wires from damage and speeding up installation in various electrical enclosures.
Specifications
- Product Type: Base Wiring Duct
- Application: Round hole design has multiple rows of holes to retain and support wire at variable heights and positions.
- Color: Light Gray
- Cover Part Number: C2LG6
- Flammability Rating: UL 94 V-0
- Includes: (1) Base
- Note: Cover sold separately
- Standards Met: RoHS Compliant, UL Recognized, CE Compliant; CSA Approved, BABA Compliant
- Material: PVC
- Material Properties: Lead-Free
- Mount Method: Mounting Holes
- Measurement System: Imperial
- Wiring Duct Style: Round Hole Wiring Duct
- Nominal Width (In.): 2
- Nominal Height (In.): 2
- Overall Length (ft.): 6
- Overall Length (m): 1.83
- Overall Width (In.): 2.25
- Overall Width (mm): 57.2
- Overall Height (In.): 2.14
- Overall Height (mm): 54.4
- Sub Brand: Panduct®
- Part Features: Round hole design retains and supports wires at variable heights and positions to enhance wire management. Smooth round edges to prevent wire abrasion. Base scoreline for easy removal for T-junctions and right angles, saving installation time.
Manufacturer Standard Package Quantity: 6
