Description
Mini-Com® TX6™ PLUS Unshielded RJ45 TG Jack Module
Mini-Com® UTP RJ45 Cat 6 TG Jack Module, Red, 100 Pack
Factory tested for reliable performance, our Category 6 TG jack module surpasses industry standards and removes the need for a traditional punchdown tool.
Specifications
- Product Type: Jack Module
- Performance Level: Category 6
- Connector Type: Jack Module - Standard
- Termination Style: TG Style
- Body Material: Polycarbonate
- Contact Material: Plated Phosphor Bronze
- Module Type: Mini-Com®
- Wiring Scheme: T568A/T568B
- Shield Type: Unshielded
- Sub Brand: Pan-Net®
- Maximum Operating Temperature (°C): 75
- Maximum Operating Temperature (°F): 167
- Minimum Operating Temperature (°C): -10
- Minimum Operating Temperature (°F): 14
- Maximum Storage Temperature (°C): 75
- Maximum Storage Temperature (°F): 167
- Minimum Storage Temperature (°C): -40
- Minimum Storage Temperature (°F): -40
- Resistance Properties: Heat-Resistant
- Color: Red
- Standards Met: Exceeds ANSI/TIA-568.2-E; ISO 11801; IEC 60603-7; IEEE 802.3af / 802.3at and 802.3bt Type 3 and Type 4, UL 1863 and UL 2043 and RoHS Compliant.
- Overall Length (In.): 1.5
- Overall Length (mm): 38.1
- Overall Width (In.): 0.62
- Overall Width (mm): 15.7
- Overall Depth (In.): 1.5
- Overall Depth (mm): 38.1
- Overall Height (In.): 0.71
- Overall Height (mm): 18
Manufacturer Standard Package Quantity: 100
