Description
Dome-Top® Barb Ty Clamp Tie
Dome-Top® BC2S-S10-D Locking Clamp Barb Tie, PA6.6, M5, 8.5"L, 50lb, PK500
Our barb ty cable tie features a unique patented design with smooth edges and a secure stainless steel locking barb, providing reliability and endless adjustment options for your cables.
Specifications
- Product Type: Locking Clamp Tie
- Sub Brand: Dome-Top®
- Color: Natural
- Environment: Indoor
- Material: Nylon 6.6
- Material Description: Nylon 6.6
- Resistance Properties: None
- Overall Length (In.): 8.5
- Overall Length (mm): 216
- Body Width (In.): 0.185
- Body Width (mm): 4.7
- Body Thickness (In.): 0.052
- Body Thickness (mm): 1.3
- Maximum Bundle Diameter (In.): 2
- Maximum Bundle Diameter (mm): 51
- Minimum Bundle Diameter (In.): 0.06
- Minimum Bundle Diameter (mm): 1.5
- Minimum Loop Tensile Strength (N): 222
- Minimum Loop Tensile Strength (lb): 50
- Compatible Screw Size: #10
- Maximum Operating Temperature (°C): 85
- Maximum Operating Temperature (°F): 185
- Minimum Operating Temperature (°C): -60
- Minimum Operating Temperature (°F): -76
- Minimum Installation Temperature (°C): -20
- Minimum Installation Temperature (°F): -4
- Mounting Hole Width (In.): 0.4
- Mounting Hole Width (mm): 10.2
- Mounting Hole Diameter (In.): 0.2
- Mounting Hole Diameter (mm): 5.1
- Standards Met: UL 62275 Compliant (Type 2, 21), UL Listed (File #E56854)
- For Use With: GTS-E, GS2B-E, GTH-E, GS4H-E, PTS, STS2
- Application: Used to secure a cable bundle to another surface such a control panel, wall or ceiling.
Manufacturer Standard Package Quantity: 500
