Description
5 pole female XLR receptacle, grounding: separate ground contact to mating connector shell and front panel, horizontal PCB mount
The 'State of the Art' receptacle. Round plastic body XLR PCB mount panel connector. These have the smallest size and highest packing density (23 mm between centres). New designed tulip type contacts with gold plating of contact area and tin plated pcb termination area.
Features & Benefits
- Smallest XLR receptacles, highest packing density
- Tulip type female contact
- Housing flammability UL94HB
- Plastic housing, steel latch lock
- Polished contact areas and hard gold plating
