Description
DESCRIPTION
Voltage monitor relay for 48 VDC, 10 Amp relay, DPDT, Adj Pick up and Drop out, Adj dropout delay 0.1-10 seconds, plug-in
The relay energizes (and the LED is Red) when the monitored voltage is above the pick-up setting for a period longer than the fixed pick-up time delay of 0.5 seconds. The relay de-energizes (and the LED is Green) when the monitored voltage is below the drop-out setting for a period longer than the fixed drop-out time delay (t) of 0.5 seconds.
FEATURES
- Monitors AC single phase and DC voltages
- True RMS Sensing ensures more accurate sensing
- Wide range of user-adjustable voltage pick-up and drop-out settings
- Adjustable time delay on drop-out of 0.1-10 seconds
- Pilot Duty Rating
- LED indicates output relay status
