Product Overview
DESCRIPTION
Time Delay Relay; Plug-in; On Delay/Off Delay; 12V AC/DC; 10A DPDT; 3-300 sec Timing Range
Upon application of input voltage, the time delay relay is ready to accept a trigger. When the trigger is applied, the time delay (t1) begins. At the end of the time delay (t1), the output is energized. When the trigger is removed, the output contacts remain energized for the time delay (t2). At the end of the time delay (t2), the output is de-energized & the time delay relay is ready to accept another trigger. If the trigger is removed during time delay period (t1), the output will remain de-energized and time delay (t1) will reset. If the trigger is reapplied during time delay period (t2), the output will remain energized and the time delay (t2) will reset.
FEATURES
- Each unit has a single timing range
- Choose from 11 separate timing ranges from 0.02 Seconds to 2 Hours
- 10A DPDT output contacts (selected functions that are normally offered with 11 pin DPDT output are also available in 8 pin SPDT versions)
- ON & OFF times on dual timer products are independently adjustable (contact Macromatic for information on ordering dual timer units with different ON & OFF time ranges)
- Pilot Duty Rating
