Macromatic TR-52221-22

$106.18
SKU:
TR-52221-22
Shipping:
Calculated at Checkout
In Stock
Available
Before Ordering

Availability and lead times may vary. Request a quote if you need to confirm availability before placing your order.

Family Owned Since 1932
Nationwide Shipping Serving all 50 states
Technical Support Product selection assistance
Project Assistance Quotes and sourcing support

Description

Description of Function

Upon application of control voltage, the time delay relay is ready to accept a trigger. When the trigger is applied, the output remains de-energized. Upon removal of the trigger, the output is energized and the time delay (t) begins. At the end of the time delay (t), the output is de-energized unless the trigger is removed and re-applied prior to time out (before time delay (t) elapses). Continuous cycling of the trigger at a rate faster than the time delay (t) will cause the output to remain energized indefinitely.

Features

  • Onboard & remote adjustable or fixed time delays from 0.05 seconds to 2 hours
  • Uses industry-standard 11 pin octal sockets
  • 10A DPDT output contacts
  • Pilot Duty Rating

Specifications

  • Function: Single Shot Falling Edge
  • CONTROL VOLTAGE: 240V AC
  • Output: 10A DPDT
  • TIMING RANGE: 0.1 – 10 Min
  • MOUNT: 11-Pin Socket
  • Setting Adjustment: Analog
  • REMOTE POTENTIOMETER: Consult Factory
  • Enclosure Style: Plug-in
  • Configuration / Contact Rating: DPDT 10A @ 240V AC / 10A @ 30V DC, 1/2HP @ 120/240V AC (N.O.), 1/3HP @ 120/240V AC (N.C.), B300 & R300
  • Approvals: UL Recognized for the U.S. and Canada, CE
  • AC Operation: +10/-15% of nominal at 50/60 Hz
  • Load (Burden): 2 VA
  • Setting Accuracy: Maximum Setting (Adjustable): +5%, -0%
  • Setting Accuracy: Minimum Setting (Adjustable): +0%, -50%
  • Fixed: ±2% or 50ms, whichever is greater
  • Repeat Accuracy: ±0.1% or ±0.04 seconds, whichever is greater
  • Reset Time: 0.04 Seconds
  • Start-up Time: 0.05 Seconds
  • Maintain Function Time: 0.01 Seconds
  • Temperature: Operating: -28° to 65° C (-18° to 149° F)
  • Temperature: Storage: -40° to 85° C (-40° to 185° F)
  • Life: Mechanical: 10,000,000 operations
  • Life: Full Load: 100,000 operations
