Product Overview
DESCRIPTION
Time Delay Relay; Plug-in; Single Shot; 120 VAC/DC; 10A SPDT; 0.6-60 Sec. Timing
Upon application of input voltage, the time delay relay is ready to accept a trigger. When the trigger is applied, the output is energized and the time delay (t) begins. During the time delay (t), the trigger is ignored. At the end of the time delay (t), the output is de-energized and the time delay relay is ready to accept another trigger.
FEATURES
- Each unit has a single timing range
- Choose from 11 separate timing ranges from 0.02 Seconds to 2 Hours
- 10A DPDT output contacts (selected functions that are normally offered with 11 pin DPDT output are also available in 8 pin SPDT versions)
- ON & OFF times on dual timer products are independently adjustable (contact Macromatic for information on ordering dual timer units with different ON & OFF time ranges)
- Pilot Duty Rating
RESOURCES
