DESCRIPTION
Timer, True Off Delay, 120VAC, 10 amp DPDT, 0.6 - 60 seconds
Upon application of input voltage, the relay is energized. When the input voltage is removed, the preset time begins. At the end of the preset time, the relay is de-energized. Voltage must be applied for a minimum of 0.1 second to assure proper operation. Any application of the input voltage during the preset time will keep the relay energized & reset the time delay. No external trigger switch is required.
FEATURES
- Each unit has a single timing range
- Choose from 11 separate timing ranges from 0.02 Seconds to 2 Hours
- 10A DPDT output contacts (selected functions that are normally offered with 11 pin DPDT output are also available in 8 pin SPDT versions)
- ON & OFF times on dual timer products are independently adjustable (contact Macromatic for information on ordering dual timer units with different ON & OFF time ranges)
- Pilot Duty Rating
