Product Overview
DESCRIPTION
Timer, Watchdog, 12VDC, 10 Amp SPDT, 0.1 - 10 hours, internal jumper to relay, jumpered trigger
Upon application of input voltage, the time delay relay is ready to accept a trigger. When the trigger is applied, the output is energized and the time delay (t) begins. At the end of the time delay (t), the output is de-energized unless the trigger is removed and re-applied prior to time out (before time delay (t) elapses). Continuous cycling of the trigger at a rate faster than the time delay (t) will cause the output to remain energized indefinitely.
DESCRIPTION
Timer, Watchdog, 12VDC, 10 Amp SPDT, 0.1 - 10 hours, internal jumper to relay, jumpered trigger
Upon application of input voltage, the time delay relay is ready to accept a trigger. When the trigger is applied, the output is energized and the time delay (t) begins. At the end of the time delay (t), the output is de-energized unless the trigger is removed and re-applied prior to time out (before time delay (t) elapses). Continuous cycling of the trigger at a rate faster than the time delay (t) will cause the output to remain energized indefinitely.
