Description
DESCRIPTION
Timer, Multi-function, 120V AC/DC, 10 Amp DPDT Output, 50ms - 10,230Hr
Available as either a multifunction version with 16 functions built-in or as individual function versions DIP-Switches for accurate digital set of time delay (multi- & single-function) & selection of function (for multi-function only) Programmable delay of 50ms – 10,230 hours (multi-function) or 100ms – 1,023 hours (single-function) LED indicates relay status Pilot Duty Rating
FEATURES
The TD-8 series of time delay relays offer an easy and accurate way to select any time delay between 50ms & 10,230 hours (100ms & 1,023 hours on single-function units). Programming is accomplished through the use of 10-position DIP-switches. This method provides a greater setting accuracy than is found on other units with an analog potentiometer. An LED indicates relay status. The TD-8 series comes in two versions: a multi-function product with 16 functions built-in or a single function product.
