Description
DESCRIPTION
Timer, On/Off Delay, 240VAC, 10 Amp DPDT Output, 1 - 1,023 seconds
Upon application of input voltage, the time delay (t) begins. At the end of the time delay (t), the output is energized. Input voltage must be removed to reset the time delay relay & de-energize the output.
FEATURES
Available as either a multifunction version with 16 functions built-in or as individual function versions DIP-Switches for accurate digital set of time delay (multi- & single-function) & selection of function (for multi-function only) Programmable delay of 50ms – 10,230 hours (multi-function) or 100ms – 1,023 hours (single-function) LED indicates relay status Pilot Duty Rating
