Macromatic TD-80528-44

$107.19
SKU:
TD-80528-44
Shipping:
Calculated at Checkout
In Stock
Available
Before Ordering

Availability and lead times may vary. Request a quote if you need to confirm availability before placing your order.

Family Owned Since 1932
Nationwide Shipping Serving all 50 states
Technical Support Product selection assistance
Project Assistance Quotes and sourcing support

Description

Description of Function

Upon application of control voltage, output is energized and the time delay (t) begins. At the end of the time delay (t), the output is de-energized. Control voltage must be removed to reset the time delay relay.

Features

  • DIP-Switches for accurate digital set of time delay
  • Uses Industry-standard 8 pin sockets
  • 10A DPDT output contacts
  • LED indicates relay status
  • Pilot Duty Rating

Specifications

  • Function: Interval On
  • CONTROL VOLTAGE: 24V AC/DC
  • Output: 10A DPDT
  • TIMING RANGE: 10 – 10,230 Min
  • MOUNT: 8-Pin Socket
  • Setting Adjustment: Digital
  • Enclosure Style: Plug-in
  • Configuration / Contact Rating: DPDT 10A @ 240V AC / 10A @ 30V DC, 1/2HP @ 120/240V AC (N.O.), 1/3HP @ 120/240V AC (N.C.), B300 & R300
  • Approvals: UL Recognized for the U.S. and Canada, CE
  • AC Operation: +10/-15% of nominal at 50/60 Hz
  • DC Operation: +10/-15% of nominal
  • Load (Burden): 2 VA
  • Constant Voltage & Temperature: ±0.1% of set time or ±50ms, whichever is greater
  • Variable Voltage & Temperature: ±1% of set time or ±50ms, whichever is greater
  • Constant Voltage & Temperature: ±0.1% of set time or ±0.02 seconds, whichever is greater
  • Variable Voltage & Temperature: ±1% of set time or ±0.02 seconds, whichever is greater
  • Reset Time: 0.1 Seconds
  • Start-up Time: 0.05 Seconds
  • Maintain Function Time: 0.01 Seconds
  • Insulation Voltage: 2kV
  • Operation: -28° to 65° C (-18° to 149° F)
  • Storage: -40° to 85° C (-40° to 185° F)
  • Life: Mechanical: 10,000,000 operations
  • Life: Full Load: 100,000 operations
