Product Overview
DESCRIPTION
3-phase monitor relay, 190-500 VAC, 8 pin SPDT 10 amp relay, phase loss, phase reversal - fixed
When the proper 3-phase line voltage is applied to the unit and the phase sequence (rotation) is correct, the relay is energized. A phase loss or phase reversal condition will de-energize the relay after a delay. Re-energization is automatic upon correction of the fault condition. A bi-color status LED indicates normal condition and also provides specific fault indication to simplify troubleshooting (see right).
FEATURES
Protects against phase loss & phase reversal Universal voltage range of 190-500V–greater range that covers more global applications (separate 575V-only version available) True RMS voltage measurement ensures accurate sensing across more applications Retains fault indication and continues monitoring all voltages even with a lost phase Full fault indication on top of unit for easy troubleshooting
