Product Overview
DESCRIPTION
Horn-Paging-30W, 70/25V, Universal Swivel Mount Bracket, Beige
Re-entrant horn LH-30TA with high efficiency 30W compression driver is for indoor or outdoor use applications requiring signaling or public address with high intelligibility, such as schools, recreational facilities, warehouses, distribution centers, parking facilities and commercial buildings. All-metal construction with beige finish. Optional wiring compartment covers for IP66 rating. A 15W horn is also available.
FEATURES
- Performance: Clear loud paging and tone signaling
- Driver: 30W compression
- Transformer: For 25V, 70V or 100V systems. Screwdriver-adjustable tap selector and screw terminal connections in rear. Integral strain relief and plastic cover.
- Enclosure: Weather-resistant assembly is all-metal construction with durable beige epoxy finish.
- Mounting Aids: Universal swivel mounting bracket
- Ships ready for installation
- Diameter: 10.37 in.
- Depth: 10.63 in.
- Installation: Indoor/outdoor surface-mount with two-wire hook-up to rear access screw terminals
- Operating Temperature Range: -40F to 158F
- Average Sensitivity (1W/1M): 118.1dB
RESOURCES
