Product Overview
Basic Operation:
The Leviton High Bay Microwave 0-10V Fixture Mount Occupancy Sensor (OSMHB-VDW) is a 5.8 GHz highfrequency motion sensor designed to mount directly to a 0-10V fixture for occupancy detection and multi-level control with adjustable time-outs. A built-in photocell reads brightness values, so the sensor does not switch the luminaire ON if sufficient ambient light is present. Control parameters are manually selected using the DIP Switches on the device or with the optional ZLS0R-RC1 IR Remote to obtain desired configuration parameters. These include adjustable sensitivity, hold time, lux level or daylighting hold-off, stand-by light level and stand-by hold time. Use the ZLS0R-RC1 Remote to store and transmit sensor profiles to other OSMHB-VDW devices if configuration requirements are the same. The OSMHB-VDW is suited for high bay fixtures and has a maximum mounting height of up to 50ft and an adjustable coverage radius of up to 30ft.
Applications
- Warehouses
- Manufacturing
- Indoor parking garages
Installation
The OSMHB installs directly to an industrial LED fixture or an electrical junction box through a standard 1/2” knockout using the provided lock-nut. Wiring is connected inside the fixture body. A metal shield can be used to shield or limit field-of-view. The OSMHB can be used with Leviton offset adapters such as the OSFOA or OSFLO to improve field-of-view (sold separately).
Features
- Tri-level dimming control
- Programmable dim-to-min light levels and time outs
- Specifically designed for LED fixture control
- Suitable for use in standard and cold storage applications
- Can be used to comply with IECC, ASHRAE 90.1, and 2019 Title 24, Part 6 occupancy/vacancy sensing and dimming requirements
- Visual RGB LED indicators for device states and easy troubleshooting
- Adjustable hold-times
- Pre-stripped color-coded wire leads
- Suitable for mounting heights 8’-50’
- Quicksnap feature for easy installation
- H.I.S. (High Inrush Stability) Technology
- Zero crossing circuitry
- Robust mechanical latching relay
- Relay always returns to close after power loss event
- UL listed for electronic ballast loads 120/277V
