Product Overview
4-1/2'' Cup & Die Set (4'' Conduit)
The HPS series comes standard with both the Cup & Die set that is used in conjunction with the various punch tools offered by Dottie. They are manufactured with a 3 point design that eliminates the slug binding in the cup and are dual rated for steel and stainless steel. The set also comes with laser etched centering lines on the cups for easy alignment as well as size and part number identification on the cup and die. Their unique design requires 50% less torque than competing brands and are interchangeable with competing brands of tools.
Specifications
Physical Characteristics
Type
Punch Tool Set
Size
4-1/2''
Material
High Speed Alloy Steel
Finish
Black Oxide
Packaging Details
Standard Qty
1
Price Per
1
Package Length
6.2
Package Width
6.2
Package Height
5.2
Package Weight
6.85
Net Weight
6.85
Performance Data
Intended Cutting Material
Steel & Stainless Steel
Conduit & Pipe Size
4''
Applications
Used in Conjunction with Hole Punch Tools
Special Features
Centering Lines Laser Etched on Cups for Easy Alignment, Size Laser Etched on Cups & Dies, Dies Require 50% Less Torque Than Competitive Brands, 3 Point Die Design Eliminates Slug Binding in Cup, Cups & Dies Interchangeable with Competing Brands
Certifications
RoHS Compliant
No
Resources & Downloads
Other Information
Dottie orders are subject to a $200 combined order minimum. Please contact us about possible orders under this amount.
