Description
- 1-1/2" Inside Diameter
- Color - Black
- Length - 50' Long
- Material - Flame Retardant Polypropylene
- MADE IN NORTH AMERICA
- Center Split, Easy To Install
- Self-Extinguishing
- Operating Temperatures From -40F to 275F
- Flame Test: Rated As V2 According to UL-94
- Extremely Flexible & Has Very Good Chemical & Abrasion Resistance
- Black Color Allows For Natural UV Protection
- Approved by ABYC for use in the marine industry
- Blue Stripe For Flame RetardantLoom Identification
- REACH & RoHS COMPLIANT
Kable Kontrol Polypropylene Flame Retardant Wire Loom Tubing - Split 1-1/2" Inside Diameter is manufactured to meet the stringent requirements of the marine and emergency vehicle industries where extra protection is necessary. FR wire loom meets UL 94-V2 rating for flame retardancy. The high rise ridge of this Flame retardant loom tubing offers greater flexibility without twisting, tangling, or slit separation. It is distinctly identified by a blue stripe running its entire length.
While some protective tubing is rigid, our Flame Retardant Polypropylene Wire Loom fully guards your vital cables and wiring against not only intense heat but also abrasion, chemicals, impact, and crushing, while retaining all the flexibility your cables had before.
Performance Enhancers
Flame Retardant - Yes
UV Inhibitor - No
Heat Stabilizer - Yes
Performance Characteristics
Flexibility - Excellent
Abrasion Resistance- Good
Chemical Resistance- Good
Recommended Operating Upper Temperature: 275F (135C)
Recommended Operating Lower Temperature: -40F (-40C)
Typical Physical Properties - Test Method - Value - Units
Specific Gravity/Density - ASTM D792 - 1.05
Elongation @ Break- ASTM D638- 980 - %
Tensile Strength @ 25C- ASTM D638- 15.5 min. - MPa
Flexural Modulus- ASTM D790- 372 - MPa
Notched Izod Impact Test ASTM D256- 12.9 ft - lb/in
Material Certifications
Underwriters Laboratory -UL-94 V2 @ 0.8 mm
FMVSS 302-Max. Burn rate of-101.2mm / min. (1.0 mm thick)
Self-extinguishing
