DESCRIPTION
Designed to cut and strip off 5/16” to 9/16” length of wire, this cut-strip tool is the perfect tool for cutting and stripping 22-24 AWG (0.65-0.50 mm) wire for wire wrapping purposes. This cut-strip tool features the following:
FEATURES
- Biomechanically designed for maximum work efficiency
- Easy operation: place wire (up to 4 at once) in stripping slot, press the tool, and pull the wire(s)
- Dual tempered spring steel blades ensure clean nick-free cutting on 22 & 24 AWG wire
- Strip length is adjustable from 5/16” to 9/16”
- Replaceable blades can be purchased separately
SPECIFICATIONS
- Wire Gauge: 22-24 AWG (0.65-0.50 mm)
- Adjustable Strip-off Length: 1 5/16" to 1 9/16" (33.33 mm to 39.68 mm)
- Handle Color: Red
- Dimensions: 6.5 in x 1.9 in x 1.65 in (16.51 cm x 4.83 cm x 4.19 cm)
- Weight: 0.19 lb (84.444 g)
- UPC #: 811490010147
