Description
Syspend 180-Max Narrow Adapter, 1.14x4.92x3.27, Black, Aluminum
- Gasket and mounting hardware are included
PRODUCT ATTRIBUTES
- Height: 1.14 in / 29 mm
- Width: 4.92 in / 125 mm
- Depth: 3.27 in / 83 mm
- Material: Aluminum
- Color: Jet Black
- Color Code: RAL 9005
- Finish: Powder Coated
- Weight: 1 lb
DRAWINGS AND DOCUMENT DOWNLOADS
2D DXF
3D Step
Approval Agency Certificate
Installation Manual / Instruction Sheet
Spec Sheet / Engineering Specification
ADDITIONAL PRODUCT DETAILS
Syspend 180-Max Narrow Adapter can be attached to the Flange Coupling and Flange Elbow Coupling to create a narrower connection to an enclosure. Specifically designed for use with the Syspend Aluminum HMI Enclosures that have 66mm of usable depth. Does not inhibit coupling functionality.
BULLETIN NUMBER
CS5
