Product Overview

ProTek Single-Door Window Type 4 12, 36.30x23.62x11.81, Lt Gray, Steel

Solid-door cabinet provides complete physical and visual protection
Window door, made of scratch-resistant safety glass, provides visual monitoring of internal equipment while maintaining equipment protection
All seams are fully welded and ground smooth
Doors are provided with ground studs to facilitate proper bonding and grounding of the cabinet
Premium seamless, foam-in-place gasket prevents contaminants from entering the cabinet
Key-locking wing knob is included on painted steel offering, providing access control to the cabinet; two keys are included with each cabinet
Stainless steel cabinet is provided with a quarter-turn slotted latch
One set of plated, self-grounding, tapped 10-32 rack angles per EIA universal spacing standards, which can be adjusted front-to-back, is provided with each center section of the cabinet; additional tapped- or square-hole rack angles can be added to the cabinet to provide additional mounting
Wall section welded panel studs which accommodate standard panels (steel and wood available), can be ordered separately

PRODUCT ATTRIBUTES

Height: 36.3 in / 922 mm
Width: 23.62 in / 600 mm
Depth: 11.81 in / 300 mm
Protection Rating: NEMA Type 12; NEMA Type 4; NEMA Type 4X; IP55; IK10
Material: Mild Steel
Rack Units: 19
Optional Steel Panel: CP3220
Optional Wood Panel: CP3220W
Additional Rack Angles: PTRA36T or PTRA36S
Color: Light Gray
Color Code: RAL 7035
Finish: Powder Coated
Thickness: 14 ga / 1.9 mm
Weight: 93 lb

DRAWINGS AND DOCUMENT DOWNLOADS

ADDITIONAL PRODUCT DETAILS

ProTek Single-Door cabinets are an excellent, off-the-shelf choice for mounting 19-inch rack, panel-mounted devices or other electronic equipment. The cabinets are designed to provide both front and rear access to 19-inch rack-mounted equipment. They provide protection against water, dirt, corrosive agents and other contaminants. ProTek is an excellent choice for applications where space is at a premium and the only option is wall mounting. ProTek comes in a broad range of sizes, materials and configurations to meet many demanding applications.

BULLETIN NUMBER

DWS12
