Hoffman P2B1164 Proline G2 Fully-Sealed Plinth Base

Hoffman P2B1164 Proline G2 Fully-Sealed Plinth Base

$439.00
SKU:
P2B1164
Shipping:
Calculated at Checkout
Product Type:
Bases & Tops
In Stock
Available
Before Ordering

Availability and lead times may vary. Request a quote if you need to confirm availability before placing your order.

Manufacturer Information

Hoffman has a $50 fee on all air orders. This fee will be incorporated into the shipping price. Hoffman orders of $7500 or more ship for free.

Family Owned Since 1932
Nationwide Shipping Serving all 50 states
Technical Support Product selection assistance
Project Assistance Quotes and sourcing support

Description

ProLine G2 Fully Sealed Plinth (100mm Solid Base), fits 1600x400mm, Black, Steel

  • Maintains NEMA 12 rating without requiring gland plate
  • Two side gland plates for cable management options
  • Seamless polyurethane gasket (UL component recognized) provides a water-tight, dust-tight seal against moisture and contaminants
  • Optional Cable Entry Gland Plate for additional cable management solutions
  • Welded corners
  • Drill points for locating casters (not included)
  • Installation hardware included

PRODUCT ATTRIBUTES

  • Height: 3.94 in / 100 mm
  • Width: 14.4 in / 365 mm
  • Depth: 63 in / 1599 mm
  • Fits Frame: 1600x400 mm
  • Color: Jet Black
  • Color Code: RAL 9005
  • Finish: Powder Coated
  • Material: Mild Steel
  • Thickness: 14 ga / 1.9 mm
  • Weight: 42 lb

ADDITIONAL PRODUCT DETAILS

No need to use a gland plate in the base of the enclosure with the Fully-Sealed Plinth Base (100mm Solid Base), which includes fully-sealed gland plates on the sides. Solid bases can easily be joined, for convenient cable management in joined/ganged enclosures while maintaining Type 12 environmental rating.

BULLETIN NUMBER

P40
