Product Overview

Elbow 45-Degree Feed-Through, 4.00x4.00, Gray, Steel

Feed-Through 45-Degree Elbows are used for continuous runs with 45-degree turns
Connects to other wireway sections and fittings and protects wires and cables against dust in a broad range of industrial applications

PRODUCT ATTRIBUTES

Type: Elbow
Height: 4 in / 102 mm
Width: 4 in / 102 mm
Protection Rating: NEMA Type 12; IP54
Material: Mild Steel
Color: Gray
Color Code: ANSI 61
Finish: Powder Coated
Thickness: 14 ga / 1.9 mm
Weight: 2.8 lb

DRAWINGS AND DOCUMENT DOWNLOADS

ADDITIONAL PRODUCT DETAILS

Feed-Through 45-Degree Elbows are used for continuous runs with 45-degree turns. Connects to other wireway sections and fittings and protects wires and cables against dust in a broad range of industrial applications.

All dimensions are to outside surfaces. Allow .12 in. (3 mm) additional for gasket at joints. Dimension J is from intersection of center lines.

BULLETIN NUMBER

F20
