Product Overview
Closure Plate Hinged-Cover Lay-in Wireway, 2.50x2.50, Gray, Mild Steel
- Lay-in Hinged-Cover Closure Plates are used for closing and sealing the end of a wireway section or run
PRODUCT ATTRIBUTES
- Type: Closure Plate
- Height: 2.5 in / 64 mm
- Width: 2.5 in / 64 mm
- Protection Rating: NEMA Type 12; IP54
- Material: Mild Steel
- Sealing Plate Type: 90°
- Sealing Plate Quantity: 1
- Color: Gray
- Color Code: ANSI 61
- Finish: Galvanized; Powder Coated / Galvanized; Powder Coated
- Thickness: 14 ga / 1.9 mm
- Weight: 0.94 lb
DRAWINGS AND DOCUMENT DOWNLOADS
2D DXF
3D Step
Approval Agency Certificate
Data Sheet
Installation Manual / Instruction Sheet
ADDITIONAL PRODUCT DETAILS
Lay-in Hinged-Cover Closure Plates are used for closing and sealing the end of a wireway section or run.
Each sealing plate also includes one gasket and one set of screws to join sections.
BULLETIN NUMBER
F10
Other Information
Hoffman has a $50 fee on all air orders. This fee will be incorporated into the shipping price. Hoffman orders of $7500 or more ship for free.
