Product Overview
Open Frame Rack 2-Post, 96.00x20.25x15.00, Black, Aluminum
- Range of heights from 4 feet to 9 feet (24U to 58U) to match capacity requirements; 19-inch Rack Packages are 7-feet high
- Side rails are tapped on both sides with 12-24UNC threads for quick installation
- EIA Universal 5/8 inch - 5/8 inch - 1/2 inch vertical mounting hole pattern matches industry standards
- RU markings on both front and back of uprights make it easier to mount equipment
- Packed unassembled in individual cartons; assembly hardware is furnished for convenient storage and installation
- Convenient rack and cable manager packages offered with either one or two 6-inch cable managers; includes one-piece hinged cover
PRODUCT ATTRIBUTES
- Height: 96 in / 2438 mm
- Width: 20.25 in / 514 mm
- Depth: 15 in / 381 mm
- Material: Aluminum
- Rack Units: 51
- Nominal Frame Height: 8 ft. ft
- Color: Jet Black
- Color Code: RAL 9005
- Finish: Powder Coated
- Thickness: 0.14 in / 3.5 mm
- Weight: 29 lb
DRAWINGS AND DOCUMENT DOWNLOADS
2D DXF
3D Step
Approval Agency Certificate
Data Sheet
Installation Manual / Instruction Sheet
ADDITIONAL PRODUCT DETAILS
Designed for use in communication data centers and telecommunication rooms, 2-Post Open Frame Racks satisfy basic functional requirements for structuring cable. Racks are available in 3-inch or 6-inch column widths.
BULLETIN NUMBER
DOFR2
Other Information
Hoffman has a $50 fee on all air orders. This fee will be incorporated into the shipping price. Hoffman orders of $7500 or more ship for free.
