Hoffman ED1PB1 Type 4 Drawn Pushbutton Enclosure

Hoffman ED1PB1 Type 4 Drawn Pushbutton Enclosure

$65.80
SKU:
ED1PB1
Shipping:
Calculated at Checkout
Product Type:
Pushbutton Enclosures
Material:
Steel
Nema Rating:
Type 4
Height:
4.5
Width:
2.88
Depth:
2.62
Before Ordering

Availability and lead times may vary. Request a quote if you need to confirm availability before placing your order.

Manufacturer Information

Hoffman has a $50 fee on all air orders. This fee will be incorporated into the shipping price. Hoffman orders of $7500 or more ship for free.

Family Owned Since 1932
Nationwide Shipping Serving all 50 states
Technical Support Product selection assistance
Project Assistance Quotes and sourcing support

Description

Drawn Pushbutton Enclosures Type 4, 1PBx30.5mm; 4.50x2.88x2.62, Gray, Steel

  • Drawn enclosure
  • No welded seams or sharp corners
  • Cover screws outside gasket sealing surface
  • Flat or domed flanged cover
  • Grounding stud on body
  • Bonding provision on cover
  • Oil-resistant gasket
  • External welded-on mounting brackets for easy installation
  • Factory stamped 4-way pushbutton holes
  • 30.5-mm or 22.5-mm size holes

PRODUCT ATTRIBUTES

  • Height: 4.5 in / 114 mm
  • Width: 2.88 in / 73 mm
  • Depth: 2.62 in / 67 mm
  • Protection Rating: NEMA Type 12; NEMA Type 4; NEMA Type 13; IP66
  • Material: Mild Steel
  • Hole Size: 30.5 mm
  • Hole Quantity: 1
  • Mounting: 5.00 x 1.12 in / 127 x 29 mm
  • Cover Style: Flat
  • Color: Gray
  • Color Code: ANSI 61
  • Finish: Powder Coated
  • Thickness: 16 ga / 1.52 mm
  • Weight: 1.2 lb

ADDITIONAL PRODUCT DETAILS

Drawn Pushbutton Enclosures are designed to hold 30.5-mm or 22.5-mm 4-way pushbuttons and switches. These enclosures have no welded seams or sharp corners.

BULLETIN NUMBER

PB1
