Product Overview

CableTek Horizontal Cable Manager 1U Single Sided, fits 19in, Black, Composite

Snap-in mounting provision holds cable manager in place while mounting screws are installed
Robust arrowhead fingers are shaped to funnel cables into base and are made of black composite material
Robust rounded end posts support cable as it enters and leaves cable manager and maintains proper cable bend radius
Deep cable compartments allow maximum cable density
Rounded edges throughout protect cable jackets from damage
Pass-through holes on double-sided models protect cable while facilitating routing between front and back sides
Single- and double-sided units provide high cable capacity, including 5e, 6 and 6A cables
1 RU and 2 RU heights allow greater flexibility in optimizing rack capacity
Removable hinged cover opens top or bottom, snaps closed for assured cable protection and professional appearance
Double-sided model has covers on both front and back
Covers stay open during installation and maintenance procedures
Horizontal and vertical cable managers designed as a system for streamlined appearance and improved functionality
Combination head 10-32 and 12-24 screws included for mounting
Made of UL listed black composite material

PRODUCT ATTRIBUTES

Material: ABS
Rack Units: 1
Front Cross-Section Area: 4.2 in²
Fill Rate, Front Cable, Cat 5e ⌀ 0.22 in: 66
Fill Rate, Front Cable, Cat 6 ⌀ 0.25 in: 57
Fill Rate, Front Cable, Cat 6A ⌀ 0.30 in: 35
Color: Jet Black
Color Code: RAL 9005
Finish: Smooth Matte
Weight: 1.7 lb

DRAWINGS AND DOCUMENT DOWNLOADS

ADDITIONAL PRODUCT DETAILS

The CableTek Horizontal Cable Manager features heavy-duty endposts, arrowhead fingers and tool-less mounting to easily route Cat 5e, 6 and 6A cable horizontally in standard 19-in. cabinets or on 2- or 4-post open frame racks.

BULLETIN NUMBER

DACCY

Other Information

Hoffman has a $50 fee on all air orders. This fee will be incorporated into the shipping price. Hoffman orders of $7500 or more ship for free.
