Description
Features
- CloudConnector Compatible – Connects easily with
- 4K (3840x2160) resolution
- 3x (2.8~8.4mm) motorized varifocal lens
- 131 foot IR viewable range for low light/no light monitoring
- 30fps@all resolutions (H.265/H.264)
- H.265, H.264, MJPEG codec supported, multiple streaming
- Day & Night (ICR), extremeWDR, Defog
- Shock detection, Loitering, Directional detection, Face/Upper Body detection, Fog detection, Audio detection, Digital auto tracking, Sound classification, Tampering
- Motion detection, Handover, Audio event playback
- Dual SD/SDHC/SDXC memory slots (Total Maximum 512GB)
- Hallway view, WiseStream II support, IP67/IP66/IP6K9K, IK10+, NEMA 4X
- LDC support (Lens Distortion Correction)
- PoE / 12V DC, Optional 24V AC, Bi-directional audio support
- 2 configurable I/O ports
- White camera body
- Weathercap included
Specifications
Video
- Imaging Device — Size: 1/2.8"
- Imaging Device — Type: CMOS
- Resolution: 3840x2160, 3328x1872, 3072x1728, 2688x1520, 2592x1944, 1920x1080, 1600x1200, 1280x1024, 1280x960, 1280x720, 1024x768, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360, 320x240
- Max. Framerate — H.265/H.264: 30fps/25fps(60Hz/50Hz)
- Max. Framerate — MJPEG: 30fps(@8MP Max. 5fps)
- Min. Illumination (Lux) — Color(1/30sec, 30IRE): 0.05
- Min. Illumination (Lux) — BW(1/30sec, 30IRE): 0.005
- Video Out: CVBS: 1.0 Vp-p / 75Ω composite for installation, USB: Micro USB Type B. Preview and installation ONLY. Requires WiFi dongle.
Lens
- Focal Length (mm): 2.8~8.4
- Zoom Ratio — Optical: 3x
- Max Aperture Ratio (F number) — Wide: 1.2
- Max Aperture Ratio (F number) — Tele: 2.8
- Angular Field of View — Horizontal: 114°~40°
- Angular Field of View — Vertical: 62°~22°
- Angular Field of View — Diagonal: 133°~46°
- Min. Object Distance: 0.7m(2.23ft)
- Focus Control: Simple focus
- Lens Type: DC auto iris(IR corrected), P iris(IR corrected)
Pan / Tilt / Rotate
- Pan / Tilt / Rotate Range — Pan: 0°~360°
- Pan / Tilt / Rotate Range — Tilt: 0°~85°
- Pan / Tilt / Rotate Range — Rotate: 0°~355°
Operational
- Day & Night: Auto(ICR)
- Backlight Compensation: BLC, HLC, WDR, SSDR
- Wide Dynamic Range (dB): 120
- Digital Noise Reduction: SSNRⅤ
- Digital Image Stabilization: Support(built-in gyro sensor)
- Defog: Support
- Motion Detection — Quantity: 8ea
- Motion Detection — Shape: 8point Polygonal zones
- Privacy Masking — Quantity: 32ea
- Privacy Masking — Shape: 4point Quadrangle zones
- Privacy Masking — Color / Option: Gray, Green, Red, Blue, Black, White, Mosaic
- Gain Control: Off, Max gain, Manual
- White Balance: ATW, NarrowATW, AWC, Manual, Indoor, Outdoor
- LDC: Support(Fill/stretch mode)
- Electronic Shutter — Mode: Minimum, Maximum, Anti flicker, Prefer shutter control
- Electronic Shutter — Speed Range: 2~1/12,000sec
- Video Rotation: Flip, Mirror, Hallway view(90°/270°)
- Alarm Interface — In/Out: 2 configurable I/O ports
- Alarm Triggers: Analytics, Network disconnect, Alarm input, App event, Time schedule, MQTT subscription
- Alarm Events When Alarm Trigger Occurred: File upload(image): e-mail/FTP/SFTP, File upload(video clip): FTP/SFTP, Notification: e-mail, Recording: SD/SDHC/SDXC or NAS recording at event triggers, Alarm output, Handover: PTZ preset, send message by HTTP/HTTPS/TCP, Audio clip playback, MQTT: publication
- Audio In: Selectable(mic in/line in)
- Audio Out: Line out
- Light Type: IR LED
- Light Viewable Length — IR: WiseIR 40m(131.23ft)
- IR Wavelength: 850nm
Analytics
- Analytics Events — Normal: Defocus detection, Motion detection, Tampering, Fog detection, Face/upper body detection, Audio detection, Sound classification, Shock detection, Virtual area(Lotering, Intrusion, Enter/Exit, Appear/Disappear), Virtual line(Crossing, Direction) , Digital auto tracking
- Business Intelligence — Normal: People counting, Queue management, Heatmap
Network
- Ethernet: Metal shielded RJ-45(10/100/1000BASE-T)
- Video Compression: H.265/H.264: Main/Baseline/High, MJPEG
- Audio Compression: G.711 u-law /G.726 selectable, G.726(ADPCM) 8kHz, G.711 8kHz, G.726: 16kbps, 24kbps, 32kbps, 40kbps, AAC-LC: 48kbps at 16kHz
- Smart Codec: Manual, WiseStreamⅡ
- Bitrate Control: H.265/H.264: CBR or VBR, MJPEG: VBR
- Streaming — Unicast: Up to 20 users
- Streaming — Multicast: Support
- Multiple Streaming: Up to 10 profiles
- Protocol: IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SFTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, CDP, SRTP(TCP, UDP Unicast), MQTT
- Application Programming Interface — ONVIF: S, G, T
- Application Programming Interface — Others: SUNAPI(HTTP API), Hanwha Vision Open Platform
- Direct Cloud Connection: Support
Security
- OS / Firmware Protect: Encrypted firmware, Secure boot, Signed firmware
- User authentication: Digest authentication, Prevent brute-force attack
- Network authentication: IEEE 802.1X(EAP-TLS, EAP-LEAP, EAP-PEAP, MSCHAPv2)
- Secure Communication: HTTPS, WSS(WebSocket Secure), SRTP
- Access Control: IP-based access control
- Data Protect: Encryption credentials, Encrypt compress for live recording file export
- Audit: Access / System / Event Log management
- Device ID: Device certificate(Hanwha Vision Root CA)
- Secure Storage: HTPM(Hanwha Trusted Platform Module), SDcard partition encrypt(AES-256)
- Security Certificate: CyberSecurity assuarance program UL CAP(UL 2900-2-3 L2)
General
- Memory — RAM: 4GB
- Memory — Flash: 512MB
- Edge Storage — Micro SD/SDHC/SDXC: Max. 512GB x 2slot(Total 1TB)
- Edge Storage(OnCloud) — Micro SD/SDHC/SDXC: Max. 1TB x 2slots (Total 2TB) \*Hanwha Vision branded microSD cards have been certified and recommended for OnCloud edge recording.
Environmental & Electrical
- Operating Condition — Temperature: -50°C~+60°C(-58°F~+140°F)
- Operating Condition — Humidity: 0~95% RH(non-condensing)
- Operating Condition — Others: Start up should be done at above -30°C
- Storage Condition — Temperature: -50°C~+60°C(-58°F~+140°F)
- Storage Condition — Humidity: 0~90% RH(non-condensing)
- Input Voltage: PoE(IEEE802.3af, Class3), 12VDC, 24VAC
- Power Consumption — PoE: Max. 12.95W, typical 10.7W
- Power Consumption — 12VDC: Max. 11.5W, typical 9W
- Power Consumption — 24VAC: Max. 13.5W, typical 11W
- Power Redundance Failover: Support
Mechanical
- Color: White
- Material: Aluminum
- RAL Code: RAL9003
- Product Dimensions: ø180x125mm(7.09x4.92")
- Product Weight: 1,900g(4.19lb)
- Compatible Conduit Hole: 19.1mm(3/4")(M25)
- Compatible Gang Box: Single, Double, 4" Octagon, Square
Certifications & Standards
- EMC: FCC 47 CFR 15 Subpart B Class A, ICES-3(A)/NMB-3(A), CE/UKCA - EN55032 Class A, EN 50130-4, EN 61000-3-2, EN 61000-3-3, VCCI CISPR 32 Class A, RCM AS-NZS CISPR 32 Class A, KS C 9832 Class A, KS C 9835
- Safety: UL 60950-1, CAN/CSA C22.2 NO. 60950-1, IEC 62471
- Environment: IEC/EN 63000, IEC 60529 IP66, IEC 60529 IP67, ISO 20653 IP6K9K, IEC 62262 IK10+, NEMA 250 type 4X
DORI (EN62676-4 standard)
- Detect (25PPM/ 8PPF) — Wide: 49.9m(163.63ft)
- Detect (25PPM/ 8PPF) — Tele: 211.0m(692.28ft)
- Observe (63PPM/ 19PPF) — Wide: 19.9m(65.45ft)
- Observe (63PPM/ 19PPF) — Tele: 84.4m(276.91ft)
- Recognize (125PPM/ 38PPF) — Wide: 10.0m(32.73ft)
- Recognize (125PPM/ 38PPF) — Tele: 42.2m(138.46ft)
- Identify (250PPM/ 76PPF) — Wide: 5.0m(16.36ft)
- Identify (250PPM/ 76PPF) — Tele: 21.1m(69.23ft)
