Product Overview
Features
- Allows easy rack mounting of narrow equipment or items that do not have rack mounting capabilities.
- Includes two adjustable gaskets (to protect from scratching the clamped equipment) horizontal clamps.
- Designed for equipment requiring front adjustment without sliding around the shelf (ie...pushbuttons, jacks, plugs, dials etc.).
- Choice of four clamp locations depending on the depth of the equipment.
- Choice of three shelf heights (see table below).
- Mounted equipment height should be at least 1/2" shorter than shelf "panel height" to allow clearance for the gasket clamps (see table below).
- Provides a sturdy shelf without obstructing upward heat movement.
- The rear lip is folded up for extra strength & doubles as an equipment retainer.
- 14-gauge steel construction.
- Tested to nearly double the suggested load rating of 200 lbs (91 kg).
- Rugged textured RAL9005 black powder paint finish.
- TAA-compliant for GSA Schedule purchases.
- RoHS and REACH compliant.
- Manufactured in North America.
Other Information
Hammond Manufacturing orders of $1500 or more ship for free.
Features
- Allows easy rack mounting of narrow equipment or items that do not have rack mounting capabilities.
- Includes two adjustable gaskets (to protect from scratching the clamped equipment) horizontal clamps.
- Designed for equipment requiring front adjustment without sliding around the shelf (ie...pushbuttons, jacks, plugs, dials etc.).
- Choice of four clamp locations depending on the depth of the equipment.
- Choice of three shelf heights (see table below).
- Mounted equipment height should be at least 1/2" shorter than shelf "panel height" to allow clearance for the gasket clamps (see table below).
- Provides a sturdy shelf without obstructing upward heat movement.
- The rear lip is folded up for extra strength & doubles as an equipment retainer.
- 14-gauge steel construction.
- Tested to nearly double the suggested load rating of 200 lbs (91 kg).
- Rugged textured RAL9005 black powder paint finish.
- TAA-compliant for GSA Schedule purchases.
- RoHS and REACH compliant.
- Manufactured in North America.
Hammond Manufacturing orders of $1500 or more ship for free.
