Material - Aluminum die-cast: G AI SI 12 / DIN 1775
Shallow lid, deep body
Captive stainless steel lid screws
Neoprene oil and petrol resistant gasket standard. (-40ºC up to +80ºC)
EMI/RFI gasket is NOT required as lid to box connection is INSIDE the gasket seal. A patented system with special designed "teeth" in the enclosure bottom provide a lasting and corrosion secure shield.
Degree of protection NEMA 4X, IP66, DIN 40050
Temperature Range (-40ºC up to +80ºC)
Separate channel system (outside the seal)
Special developed external mounting feet made from zinc-die-cast. Can be turned through 90º. The fastening holes have engagement lugs for this purpose. (See accessories)
All sizes have inner blind holes. A mounting plate made of zinc-plated steel is available
Textured polyester powder coat, light beige/grey RAL 7032. (can be supplied unpainted on special order)
CSA certified, Type 4, for use with industrial control equipment
