Low profile, lightweight, cool running - due to high efficiency toroidal design
Dual 117/234 VAC primary, 50/60 Hz. operation
Units are designed to have all windings engaged.
Center single hole mounting - units over 225VA include a potted center (see photos below) for extra mounting strength.
Supplied with two rubber insulating pads, one metal centering washer and all mounting hardware (160VA and under)
Supplied with one bottom rubber insulating pad and mounting hardware (225VA and larger)
Center bolt size varies with VA - see tables below.
Minimum 8" long flexible leads
Hi-Pot test of 4,000V RMS between primary & secondary
CSA certified to C22.2 #66 - CSA file #209651
UL recognized to UL506 - UL file #E207860
CE certified to IEC950
Note about Inrush Current:
Due to the superior magnetic properties of Toroidal transformers they will be susceptible to high magnetizing current when initially energized, only limited by the low DC resistance of the primary winding. Depending on where you are in the AC cycle when the transformer is energized dictates the chances of overloading the supply circuit. This is why the transformer may sometimes energize without a problem and other times it will blow the fuse or trip the circuit breaker. The duration of this overload is rarely longer than a half of a cycle. Therefore, you should consider using a slow-blow fuse, time delayed circuit breaker or other form of soft start circuitry for the supply line when using these high efficient Toroidal transformers.
