Product Overview
22 AWG 4 Stranded Conductors
Ratings CMP, CL3P, FPLP, FT6
Approvals ETL Listed
Construction
Conductor 22 AWG 7 Strand Bare Copper
Conductor Count 4
Insulation Plenum PVC (0.007" nom.)
Insulation Colors Black, Red, White, Green
Lay Length 4.50" nom.
Shielding N/A
Rip Cord Yes
Jacket Plenum PVC (0.015 " nom.)
Overall Diameter 0.133" nom.
Print Legend GENESIS P/N 3104 4C 22AWG 3038058 (ETL) CL3P OR FPLP OR CMP C(ETL)US FT6 75C
(RoHS) W/O# XXXXXX-XXXXXXX XXXXFT A B C D E F 1 2 3 4 5 6 7 8 9
Properties
Operating Voltage 300 Volts max.
DC Resistance 16.9 Ohms/1000' at 20°C
Capacitance 26.0 pF/ft. nom.
Impedance 71 Ohms nom.
Temperature -20°C to 75°C
Flame Rating NFPA 262 (Plenum); CSA C22.2 No. 2556 (FT6)
RoHS Compliant Yes
Country of Origin USA
