DESCRIPTION
Model FB2LED is a multi-pattern LED available in single color and quad-color models. Single color models are available in five colors (Amber, Blue, Clear, Green, Magenta, and Red) and feature Federal Signal’s patented Power Select™ technology. PowerSelect allows a user to select one of three flash patterns (60 FPM, 120 FPM, and steady) without having to open the unit, by following a sequence when power is applied.
Quad-color models feature four colors (Amber, Blue, Green, and Red) and four flash patterns (60 FPM, 120 FPM, simulated strobe, and steady) per unit. Sixteen color and flash pattern combinations are achieved by wiring selection.
FB2LED is available in 12-24VDC and 120-240VAC. The zinc die-cast alloy base features an integrated 1/2-inch NPT pipe mount and three holes required for surface mount configurations. Vertical wall and corner mounting accessories are sold separately.
The housing for FB2LED is designed to protect against corrosion, vibration, and water- and dust-ingress and high pressure and temperature spray-downs. The unit is ideal in harsh applications including industrial warning, process control, status indication, and food processing.
FEATURES
- Available in 12-24VDC or 120-240VAC
- Quad-color models are available with a clear lens, four colors (Amber, Blue, Green, and Red, and four flash patterns) in one unit
- Single color models are available with Amber, Blue, Clear, Green, Magenta or Red LEDs/lens and have three flash patterns
- 50,000 hour LED
- Integrated 1/2-inch NPT pipe and surface mount
- Indoor/outdoor use
- Conformal coated PCBA
- Type 4X, IP66 enclosure
- IP69K compliant
- UL and cUL Listed
