Description
FEATURES
Easy installation to beam flanges
Provides optimal support for high-performance data cable, up to and including Cat 5e, Cat 6, Cat 6A, Cat 7 and fibre optic
Ready to use out of the box, saving installation time and labor
Requires no screws, rivets or special tools for assembly
Single- or double-sided tree configurations provide multiple J-Hooks with one structural attachment
Provides superior fill capacity and load rating over most other non-continuous cable support alternatives
Complies with EN 50174-2
Meets ISO®/IEC 14763-2, ANSI®/TIA 568 and ANSI®/TIA 569
PRODUCT ATTRIBUTES
Material: Steel
Finish: Pregalvanized
Type: Double Sided
Diameter: 2"
Tiers: 3
Flange Thickness: 13/16" Max
Width: 5 13/16"
Height: 15 1/4"
A: 1 1/8"
B: 2"
Torque: 8 ft lb
Static Load: 360 lb
ADDITIONAL PRODUCT DETAILS
Static loads represent maximum load limit of J-Hook tree. Static load limit of each J-Hook is 60 lb (270 N).
Setscrew must be tightened and torqued onto the sloped side of the I-beam.
Non-continuous supports may not exceed spacing of 5' (1.5 m) per TIA 569-C.9.7 and EN 50174-2.
